Resonessence Labs – Invicta Mirus Pro

Convertitore DAC stereo Hi-End. Doppio DAC Sabre ESS 9028 PRO per canale 32bit/384KHz. Tecnologia Hyperstream II. DSD (64 e 128). DXD. Ingressi USB 1.0/2.0 asincrono, S/PDIF BNC, AES, ottico e SD Card. Uscita stereo RCA e XLR. Uscita HDMI per visualizzare i parametri su un monitor esterno, commutabile come ingresso dove necessario. Sette filtri di up-sampling proprietari fino a 176,4/192KHz per ingressi a 44,1/48KHz. Word sync per clock esterno. Firmware aggiornabile. Display frontale del menù. Chassis completamente in alluminio realizzato da IMWorks.

Recensione: www.audiostream.com

Categoria: Tag:

Descrizione

Specification GeneralValueUnitsNotes

Width 22.0 (8.66) cm (in)
Depth 28.2 (11.10) cm (in)
Height 5.0 (1.97) 4.4 (1.73) cm (in) cm (in) Including feet Without feet
Weight 2.9 (6.4) kg (lb)
Operating Voltage 110 – 130 220 – 250 V AC 60Hz, 115v setting 50Hz, 230v setting
Fuse Rating 115v 500 mAmp Slow Blow, 250V, 5mm x 20mm
Fuse Rating 230v 250 mAmp Slow Blow, 250V, 5mm x 20mm
Power Consumption 30 Watts
SD Card File Format DSF, DFF, FLAC, WAV, AIFF Up to 384kS/s, 24bit

XLR Output

Amplitude 4.6 ±5% Vrms At 0dB volume
Impedance 78 ±1% ohm
Distortion + Noise < -114 < 0.0002 dB % 1kHz
Dynamic Range > 130 dB A-weighted
Frequency Response < 0.25 < 1.0 < 3.0 dB dB dB at 20kHz 44.1kS/s at 50kHz 192kS/s at 80kHz 192kS/s

RCA Output

Amplitude 2.3 ±5% Vrms At 0dB volume
Impedance 39 ±1% ohm
Distortion + Noise < -114 < 0.0002 dB % 1kHz
Dynamic Range > 125 dB A-weighted
Frequency Response < 0.25 < 1.0 < 3.0 dB dB dB at 20kHz 44.1kS/s at 50kHz 192kS/s at 80kHz 192kS/s
